Four Stroke Cummins Air Cooled Generator 50HZ Rated Frequency Water Cooling

Name: Four Stroke Cummins Air Cooled Generator 50HZ Rated Frequency Water Cooling
Brand: BOSS OR OEM
Price: 1 USD

Quality Four Stroke Cummins Air Cooled Generator 50HZ Rated Frequency Water Cooling wholesale

Brand Name : BOSS OR OEM

Model Number : BS C series

Certification : CE, ISO

Place of Origin : China

MOQ : 1 units

Payment Terms : L/C, T/T, Western Union

Supply Ability : 100 units per month

Delivery Time : 25-30 days

Packaging Details : Plywood Box or Plastic File and Foam

Price : negotiable

Frequency : 50Hz or 60Hz

Rated power : 30-1650kva

Engine : DCEC Cummins

Alternator : Stamford , Leroy Somer , Meccalte Alternator

Contact Now

50Hz Global Warranty Super Silent 100kva Cummins Diesel Generator with OEM Supply

Product Description

1. Specification of Genset
Gensets Model	BS-C100
Prime/ Standby Power	80kw/100kva 88kw/110kva
Rated Voltage	380/220V
Rated Frequency (HZ)	50
Rated Speed	1500rpm
Power Factor	0.8(lagging)
Dimensions (mm) (L×W×H)	1710x700x1340
Genset Weight (kg)	960
2. Specification of Diesel Engine
Engine Brand	Optional
Engine Model	/
Number of Cylinders	6
Cylinder Arrangement	Vertical in-line
Cycle	Four stroke
Aspiration	Turbocharged, Water cooling
Fuel System	PT type fuel pump, EFC
Bore×Stroke (mm×mm)	159 x 159
Displacement (Liter)	50.3
Compression Ratio	13.9:1
Speed Governor	Electronic
Cooling System	Forced Water Cooling Cycle
Total lubrication System Capacity (L)	95
Fuel Consumption at 100% Load (L/H)	57
Starting Method	DC24V electrical starting
3. Specification of Alternator
Alternator Brand	Stamford / Meccalte
Alternator Model	UCI 274C
Number of Phase	3
Connecting Type	3 Phase and 4 Wires
Number of Bearing	1
Protection Grade	IP21
Altitude	≤1000m
Exciter Type	Brushless ,Self-exciting, AVR automatic voltage regulating,100% Copper winding wire
Insulation Class	H
Telephone Influence Factor (TIF)	≤50
THF	≤2%
Voltage Regulation, Steady State	≤±1%
Transient State Voltage	≤-15%~+20%
4. Specification of Control Panel (with Deepsea Controller)
The control panel is AMF control panel, with the display of voltage,current, frequency, water temperature, oil pressure. The genset with low oil pressure, high water temperature,over speed, over load protection function.
The features of Deepsea controller:
Deepsea controller is a new generation automatic control module for single genset, which adopts bran-new outline configuration, focus on the requirements of customers, and perfectly improves the performance of controller. It fully meets the auto control requirements of different kinds of genset for user or special assembly factory

Four Stroke Cummins Air Cooled Generator 50HZ Rated Frequency Water Cooling

FAQ

Q : Do you offer OEM service?
A : Yes

Q : What is the difference between Prime power and Standby power?
A : Prime power is 12hours continous power,one hour 10% over load in every 12 running hours is allowed .
Standby power is the limit value of maximum output for emergency use . Overloading is prohibited
Q : What about the warranty
A : Guarantee for one year or 1000 hours (accord to whichever reach first) from ex-factory date .During the

guarantee period ,our company will provide the free easy damaged spare part for problems caused by our

quality of production or raw material except the damageable spare parts of diesel engine caused by

customer's incorrect man made operation . After expiration , our company provides cost parts maintenance

for gen-set.
